Description
Laser spot welding is an important aspect of the application of laser processing technology. The spot welding process is heat conduction, that is, laser radiation heats the surface of the workpiece, and the surface heat diffuses into the interior through thermal conduction, and the workpiece is melted to form a specific molten pool by controlling the width, energy, peak power and repetition frequency of the laser pulse. Because of its unique advantages, it is widely used in the welding process of gold and silver jewelry and small parts.
Product Parameter
| SPECIFICATIONS FOR JEWELRY LASER WELDING MACHINE | |
| Model | RL-Y80 |
| Laser output power | 80W |
| Laser type | YAG pulse |
| Laser wavelength | 1064um |
| Pulse width | 0.1ms-20ms |
| Pulse energy | 50J |
| Pulse frequency | 0-50Hz |
| Size of welding spot | 0.2mm-2.0mm |
| Adjusting range of light spot | 1.8mm |
| Max. bearing of work bench | 25KG |
| Repeating precision of work bench | -0.001 |
| Positioning precision of work bench | -0.001 |
| Sighting positioning system | HD-CCD monitor system |
| Cooling method | Water cooling |
| Max. output power | 250W |
| Integrity power | 5KW |
| Power supply | AC220VAC/380VAC+-15%/50HZ/25A |
| Guarantee | 1 year |
Key Technical Advantages:
-
High-power 80W laser output with adjustable pulse energy up to 50J
-
Wide parameter adjustment range (0.1-20ms pulse width, 0-50Hz frequency)
-
Precision spot size control from 0.2mm to 2.0mm (±1.8mm adjustment)
-
Ultra-precise workbench with 0.001mm positioning accuracy (25kg capacity)
-
Advanced HD-CCD monitoring system for perfect weld positioning
Industry-Leading Features:
-
Versatile Welding Control – Adjust energy, pulse width, frequency and spot size for perfect results on any material
-
Durable Ceramic Cavity – Corrosion-resistant design with 8-10 year service life
-
Eye Protection System – Advanced light shielding eliminates harmful radiation
-
Ergonomic Design – Comfortable operation for extended work sessions
Applications:
Ideal for:
-
Gold/silver jewelry welding and repair
-
Precision welding of dental implants (titanium alloy)
-
Micro-welding in electronics manufacturing
-
Automotive and medical instrument components
-
Golf club heads and precision machinery parts
Why Choose RL-Y80?
→ Unmatched precision for jewelry applications
→ Long-lasting components reduce maintenance costs
→ Safe operation with advanced eye protection
→ Energy efficient design lowers operating costs
Upgrade your production capabilities with the RL-Y80 – the professional choice for jewelry manufacturers and precision welding applications worldwide.
